最全的京瓷3225有源晶振型號編碼大全速度收藏了

來源：http://m.py519.com 作者：億金電子 2017年10月19

國際知名品牌KYOCERA晶振（簡稱KSS晶振）,所有的生產線都具備順應時代變化的速度感,通過融合集團的獨特技術,進一步積極創造新產品、開拓新市場.為了回應客戶的期待,京瓷晶體振蕩器,有源晶振,石英晶振 ,壓控振蕩器,在價格、質量、服務等所有方面都滲透“客戶第一”的理念,不斷為全球市場奉獻新價值.

京瓷所生產石英貼片晶振被廣泛用于世界各行各業,晶振均符合歐盟ROHS歡迎要求.京瓷3225有源晶振是如今市場使用最火的封裝尺寸,小小的體積具有高穩定精度,具有多種電源電壓可供用戶選擇,常用工作溫度在-40~85℃范圍,在惡劣的環境中使用也能夠保持±50ppm精度,具有CMOS,LVDS等多種輸出,高精度,高品質,耐高溫等特點.

億金電子代理日本京瓷晶振,貼片晶振從2016~7050封裝,型號頻率齊全可免費提供樣品,更有晶振型號編碼免費下載,其中包括TCXO溫補晶振,LVDS差分晶振,VC-TCXO壓控溫補晶振,VCXO晶振,XO石英晶體振蕩器,SPXO振蕩器等一系列石英晶體振蕩器型號編碼.以下為億金京瓷晶振代理商整理提供的日本KYOCERA京瓷3225有源晶振型號編碼查詢表,精度,電源電壓,工作溫度,輸出方式等資料一應俱全.

京瓷晶振編碼	頻率	輸出	電壓	頻率穩定度	京瓷晶振封裝尺寸
KC3225K40.0000C1GE00	40MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K20.0000C1GE00	20MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K27.0000C1GE00	27MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K32.0000C1GE00	32MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K33.3333C1GE00	33.3333MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K48.0000C1GE00	48MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K50.0000C1GE00	50MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K1.84320C1GE00	1.8432MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K7.37280C1GE00	7.3728MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K8.00000C1GE00	8MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K10.0000C1GE00	10MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K12.0000C1GE00	12MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K14.7456C1GE00	14.7456MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K18.4320C1GE00	18.432MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K32.7680C1GE00	32.768MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K33.0000C1GE00	33MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K60.0000C1GE00	60MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K66.6667C1GE00	66.6667MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A50.0000C3GE00	50MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A16.0000C3GE00	16MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A12.0000C30E00	12MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A25.0000C30E00	25MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A50.0000C30E00	50MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K24.0000C1GE00	24MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A125.000C30E00	125MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A100.000C30E00	100MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A125.000C20E00	125MHz	CMOS	2.5V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K16.0000C1GE00	16MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K80.0000C1GE00	80MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A40.0000C30E00	40MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A24.5760C30E00	24.576MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A27.0000C30E00	27MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A14.3182C3GE00	14.3182MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A20.0000C3GE00	20MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A1.84320C3GE00	1.8432MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A19.2000C3GE00	19.2MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A48.0000C3GE00	48MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A12.0000C3GE00	12MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A4.00000C3GE00	4MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A40.0000C3GE00	40MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A10.0000C3GE00	10MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A7.37280C3GE00	7.3728MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A27.0000C3GE00	27MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A54.0000C30E00	54MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A60.0000C3GE00	60MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A100.000C20E00	100MHz	CMOS	2.5V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A125.000C3GE00	125MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A100.000C3GE00	100MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A72.0000C30E00	72MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A106.250C30E00	106.25MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225F16367ACW30TA0	16.367MHz	Clipped Sine Wave	3V	±500ppb	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225F16369ACW28TA0	16.369MHz	Clipped Sine Wave	2.8V	±500ppb	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225F27456ZAW28TA0	27.456MHz	Clipped Sine Wave	2.8V	±500ppb	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K24.5760C1GE00	24.576MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K3.68640C1GE00	3.6864MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K4.00000C1GE00	4MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K14.3182C1GE00	14.3182MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K16.3840C1GE00	16.384MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K2.04800C1GE00	2.048MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K22.5792C1GE00	22.5792MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K28.6364C1GE00	28.6364MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K75.0000C1GE00	75MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K12.2880C1GE00	12.288MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A48.0000C30E00	48MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A24.5760C3GE00	24.576MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A3.68640C3GE00	3.6864MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A8.00000C3GE00	8MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225T32768EAW30TAA	32.768kHz	CMOS	3V	±5ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K25.0000C1GE00	25MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K11.2896C1GE00	11.2896MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K13.5600C1GE00	13.56MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A24.0000C3GE00	24MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A25.0000C3GE00	25MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A80.0000C3GE00	80MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K1.84320C10E00	1.8432MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K2.04800C10E00	2.048MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K3.68640C10E00	3.6864MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K4.00000C10E00	4MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K7.37280C10E00	7.3728MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K8.00000C10E00	8MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K10.0000C10E00	10MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K11.2896C10E00	11.2896MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K12.0000C10E00	12MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K12.2880C10E00	12.288MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K13.5600C10E00	13.56MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K14.3182C10E00	14.3182MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K14.7456C10E00	14.7456MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K16.0000C10E00	16MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K16.3840C10E00	16.384MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K18.4320C10E00	18.432MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K20.0000C10E00	20MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K22.5792C10E00	22.5792MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K24.0000C10E00	24MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K24.5760C10E00	24.576MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K25.0000C10E00	25MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K27.0000C10E00	27MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K28.6364C10E00	28.6364MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K32.0000C10E00	32MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K32.7680C10E00	32.768MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K33.0000C10E00	33MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K33.3333C10E00	33.3333MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K40.0000C10E00	40MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K48.0000C10E00	48MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K50.0000C10E00	50MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K60.0000C10E00	60MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K66.6667C10E00	66.6667MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K75.0000C10E00	75MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225K80.0000C10E00	80MHz	CMOS	1.6 V ~ 3.63 V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A18.4320C3GE00	18.432MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A30.0000C3GE00	30MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A44.0000C3GE00	44MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A106.250C3GE00	106.25MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A14.3182C30E00	14.3182MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A30.0000C30E00	30MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A49.1520C30E00	49.152MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KC3225A75.0000C30E00	75MHz	CMOS	3.3V	±50ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225K26000ZAW25TCS	26MHz	Clipped Sine Wave	2.8V	-	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225T32768DAW33T	32.768kHz	CMOS	3.3V	±3.8ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225R40000ECV28TBA	40MHz	Clipped Sine Wave	2.8V	±2.5ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
KT3225R26000ZAW28TMA	26MHz	Clipped Sine Wave	2.8V	±5ppm	0.126" L x 0.098" W (3.20mm x 2.50mm)
